High Country Tek DVC80 User Manual
Page 48

P/N: 021-00154, Rev. A.6 - updated for V4.7 Tools
Page | 48
LED STATE
MEANING
Off
There is no power applied to the module.
On
GREEN
The module is operating in a normal condition.
Flashing
GREEN
Device is in standby state. May need servicing.
On
RED
Module has an unrecoverable fault.
Flashing
RED
Recoverable
fault.
Flashing
RED
/
Green
This DVC7 was loaded with an application that was
compiled for a DCV10 or DVC5. The DVC7 is not
operational in this condition. Recompile the application
as a DVC7 type and load that application.
LED1 and LED2: Network Status
LED STATE
MEANING
Off
There is no J1939 device (or other DVCs) in the
project.
On
GREEN
J1939/CAN Bus communication has been established.
Flashing
GREEN
J1939/CAN Bus device in project but communication
has not been established. Flash 2 times in 2 seconds.
On
RED
The device has detected an error that has rendered it
incapable of communicating on the network.
Flashing
RED
The J1939 communication is in a timed-out state.
Flash 2 times in 2 seconds.
Normal Operation
Length: Until the next power cycle
Summary:
LED1 shows Network status
LED2 shows max PWM
LED3 error, System Enable or module ready
LED4 is the error code if any set by the blinkcode or open/short detection
LED1: Network Status (Same as Power On)
LED STATE
MEANING
Off
There is no J1939 device (or other DVCs) in the
project.
On
GREEN
J1939/CAN Bus communication has been established.
Flashing
GREEN
J1939/CAN Bus device in project but communication
has not been established. Flash 2 times in 2 seconds.
On
RED
The device has detected an error that has rendered it
incapable of communicating on the network.
Flashing
RED
The J1939 communication is in a timed-out state.
Flash 2 times in 2 seconds.
LED2: PWM Status
