** Power and GND are not supplied to the CAN Bus by the DVC5
10.2 DVC7 Hardware Connections
DVC7
30 Pin Metri-Pak connector
Pin Function Pin Function Pin Function
L1 RS232 TXD P2 ANA 1 T3 DIG 3
L2 RS232 RXD P3 GND W1 PWM 1
L3 RS232 RTS R1 UNI 2 W2 PWM 2
M1 CAN H R2 ANA 2 W3 HS 5
M2 GND R3 REF OUT X1 HS 2
M3 GND S1 UNI 3 X2 HS 4
N1 CAN L S2 DIG 1 X3 HS 6
N2 GND S3 DIG 2 Y1 (+) POWER IN
N3 GND T1 HS 1 Y2 (+) POWER IN
P1 UNI 1 T2 HS 3 Y3 (+) POWER IN
10.3 DVC10 Hardware Connections
DVC10
30 Pin Metri-Pak connector (P1)
Pin Function Pin Function Pin Function
A1 RXD D2 UNI 2 INPUT G3 DIG 2 INPUT
A2 TXD D3 SIG COM H1 ANA 3 POT REF
A3 RTS E1 UNI 3 POT REF H2 ANA 3 INPUT
B1 SIG COM E2 UNI 3 INPUT H3 DIG 3 INPUT
B2 SIG COM E3 SIG COM J1 DIG 4 INPUT
B3 SIG COM F1 ANA 1 POT REF J2 DIG 5 INPUT
C1 UNI 1 POT REF F2 ANA 1 INPUT J3 DIG 6 INPUT
C2 UNI 1 INPUT F3 DIG 1 INPUT K1 (+) POWER IN
C3 SIG COM G1 ANA 2 POT REF K2 DIG 7 INPUT
D1 UNI 2 POT REF G2 ANA 2 INPUT K3 DIG 8 INPUT
DVC10
18 Pin Metri-Pak connector (P2)
Pin Function Pin Function
A1 (+) POWER IN D1 HS OUT 5
A2 (+) POWER IN D2 HS OUT 6
