Print Options
The Print Options parameter determines which values
are printed in response to a Print Request command or user
input print request.
-27-
Print and Reset Count
This parameter is used in conjunction with Print Request
(User Input or Serial Command) and the Print Options to
determine whether or not all count values are reset after
being acquired for serial transmission.
Prescaler Output Pulse at [Prescaler Output Model Only]
This parameter selects if the Prescaler Output pulse
occurs when the 1’s or 10’s digit of the Count value
changes. See Prescaler Output, page 36, for more details.
Prescaler Output Pulse Length (1-9)
[Prescaler Output Model Only]
This parameter determines the Prescaler Output Pulse
width. The Prescaler Output activates on falling edges of
the count signal. Once activated the Prescaler Output Pulse
will remain activated for the number of positive count
(input) edges specified by the Parameter. See Prescaler
Output, page 36, for more details.
PrnOPt
3
PScOAt
1 dig
PScLEn
1
PrnrSt
no
MODE NUMBER
Dual
Preset
Model
Preset
Values
Counter (1)
Value
Prescaler
Value
PRINT
Counter 2
Value
01 01 √
02 02 √
03 03 √ √
04 04 √
05 05 √ √
06 06 √ √
07 07 √ √ √
08
√
09 √ √
10 √ √
11 √ √ √
12 √ √
13 √ √ √
14 √ √
Batch Models
√
√ √ 15 √
Batch Model
√
Dual Preset Model
MODE DESCRIPTION
no Do not reset count after Print.
YES Each Count Value specified in Print Options will
reset after being printed (transmitted on Serial)
when a Print Request is issued.
Prescaler Output Pulse activates when 10’s digit
of counter changes.
10 dig
1 dig
DESCRIPTION MODE
Prescaler Output Pulse activates when 1’s digit
of counter changes.
