Access Output Time Values
This parameter configures the type of access given to
each Output Time Value when in normal operating mode
with Programming disabled (See Front Panel Accessible
Functions With Program Disable, page 14, for more details).
The accessibility of each Output Time Value can be
individually configured.
Programming Keys:
C
- Selects Output Time Value being configured as
indicated by the number on the left of the bottom display.
B
- Changes mode selection for selected Output Time
Value.
Output Resolution
This parameter configures the timed output resolution for
all available Timed Outputs. Use the 0.01SEC resolution if
all Output Time Values are below 99.99 seconds.
-23-
Output 1 Time Value
The Output 1 Time Value controls the Output 1 duration,
when Output 1 is set for timed mode of operation ( OPEr or
OPEr 1 parameter). The Output time value range will be
0.01-99.99 Seconds or 0.1-999.9 seconds, depending on the
setting of the Output Resolution (
OutrES ) parameter.
Output 2 Time Value (Dual Preset/Batch
Models only)
The Output 2 Time Value controls the Output 2 duration,
when Output 2 is set for timed mode of operation ( OPEr or
OPEr 1 parameter). The Output time value range will be
0.01-99.99 Seconds or 0.1-999.9 seconds, depending on the
setting of the Output Resolution (
OutrES ) parameter.
Output 3 Time Value (Batch Model only)
The Output 3 Time Value controls the Output 3 duration,
when Output 3 is set for timed mode of operation ( OPEr 2
parameter). The Output time value range will be 0.01-99.99
Seconds or 0.1-999.9 seconds, depending on the setting of
the Output Resolution (
OutrES ) parameter.
Reverse Output Logic
This parameter individually configures whether or not the
Output Logic is reversed, for all Preset Outputs.
Ac Out
-L-L-L
OutrES
0.01SEC
rEVOut
-n-n-n
OutPut
1
t 0.10
OutPut
2
t 0.10
OutPut
3
t 0.10
MODE DESCRIPTION
-L
-y
-n
-P Protected Value; Output Time Value is viewable and
changeable in Protected Value Menu only. It is not
viewable at Main Display.
MODE DESCRIPTION
0.01SEC 0.01 Second Output Resolution; Maximum
Output time: 99.99 Seconds
0.1 SEC 0.1 Second Output Resolution; Maximum
Output time: 999.9 Seconds
Dual Preset/
Batch Models
Batch Model
MODE DESCRIPTION
-n
-Y
Locked; Output Time Value is not viewable at main
display or in Protected Value Menu. The Output Time
Value can only be viewed or changed in the
Programming Menu.
Yes; Output Time Value is viewable and changeable
at main display when at 1st level program disable.
Value is not shown in Protected Value Menu.
No; Output Logic is not Reversed. Output / Relay
will turn ON at Preset Value or Zero (Reset to
Preset modes) and turn OFF when Reset or
Output Time expires.
Yes; Output Logic is Reversed. Output / Relay will
turn OFF at Preset Value or Zero (Reset to Preset
modes) and turn ON when Reset or Output Time
expires.
No; Output Time Value is viewable only and not
changeable from main display when Programming is
Disabled. Value is viewable and changeable in the
Protected Value Menu.
