SINGLE PRESET OPERATING MODES
Use either of the two charts below for more information on specific operating
modes.
-19-
MODE# RESET TYPE
Manual
Auto
RESET
T
o
Zero
T
o
Preset
at
T
imed
Output
End
OUTPUT 1
Latched
T
imed
√ √ √ 1
2
√ √ √
3 √ √ √
√ √ √ 4
√ √ √ 5
√ √ √ 6
√ √ √ √ 7
√ √ √ √ 8
SINGLE PRESET OPERATING MODES
Auto Reset to Preset at Timed Output End - 8
Auto Reset to Zero at Timed Output End - 7
Auto Reset to Preset, Timed Output - 6
Auto Reset to Zero, Timed Output - 5
Manual Reset to Preset, Timed Output - 4
Manual Reset to Preset, Latched Output - 3
Manual Reset to Zero, Timed Output - 2
Manual Reset to Zero, Latched Output - 1 1 - Manual Reset to Zero, Latched Outputs
2 - Manual Reset to Zero, 01 Timed, 02 Latched
3 - Manual Reset to Zero, 01 and 02 Timed
4 - Manual Reset to Zero, 01 off at 02, 02 Latched
5 - Manual Reset to Zero, 01 off at 02, 02 Timed
6 - Manual Reset to Preset 2, Latched Outputs
7 - Manual Reset to Preset 2, 01 Timed, 02 Latched
8 - Manual Reset to Preset 2, 01 and 02 Timed
DUAL PRESET AND BATCH COUNTER 1 OPERATING MODES
9 - Manual Reset to Preset 2, 01 off at 02, 02 Latched
10 - Manual Reset to Preset 2, 01 off at 02, 02 Timed
11 - Auto Reset to Zero, 01 and 02 Timed
12 - Auto Reset to Zero, 01 off at 02, 02 Timed
13 - Auto Reset to Preset 2, 01 and 02 Timed
14 - Auto Reset to Preset 2, 01 off at 02, 02 Timed
15 - Auto Reset to Zero at 02 End, 01 and 02 Timed
16 - Auto Reset to Zero at 02 End, 01 off at 02, 02 Timed
17 - Auto Reset to Preset 2 at 02 End, 01 and 02 Timed
18 -
DUAL PRESET/ BATCH COUNTER 1 OPERATING MODES
Use either of the two charts below for more information on specific
operating modes.
Auto Reset to Preset 2 at 02 End, 01 off at 02, 02 Timed
