About Locations
viewLinc 4.1 Administrator Guide 67
Understanding the Locations Screen
The Locations screen in viewLinc contains many important
features:
2
3
5
4 1
Item Details
1 - Tabs Contains main viewLinc tabs: Table View, Dash-
board, Location Alarms, Trend.
2 - Options
dropdown Contain buttons like Refresh, Popup Trend, Pause
Alarming, etc. These menus are context-sensitive
- they change depending on which tab is open
and which item is selected within the tab.
3 - Zones area Where configuration of locations and zones takes
place. Use the locations tree to organize the loca-
tions that are connected to viewLinc into zones.
Zones are represented by folders with Locations
located below them in the tree. Locations are
found below the zones. The table view on the
right will display information about the zone or
location that you have selected.
4 - Search You can search for locations here by entering a
search term in the text box and clicking the mag-
nifying glass icon.
Table 2: Important features of the Locations screen
