OmniSwitch Troubleshooting Guide September 2005 page -169
debug vlan communication
Displays the communication of the Chassis management Module (CMM) with all the software modules
and all Network Interface (NI) modules.
debug vlan communication
Syntax Definitions
N/A
Defaults
N/A
Platforms Supported
OmniSwitch 6624, 6648, 7700, 7800, 8800
Usage Guidelines
• GlobSlice indicates the slot number.
• If an NI is not present in the chassis then the state will appear as dead.
Examples
-> debug vlan communication
***CMM Connections***
CS Ping sid= 1c rap= 64 rsp= 6 CNXNLESS NO-RX notify=0
defaults assumed=1
txrty=0 txfail=0 bfrty=0
SL VPA sid= 26 rap= 10 rsp= 7 CNXN-OR NO-RX notify=0
defaults assumed=0
txrty=0 txfail=0 bfrty=0
802.1Q sid= 1e rap= 7 rsp= 3 CNXN-OR ESTABLISHED notify=5
defaults assumed=1
txrty=0 txfail=0 bfrty=0
Port Mgr sid= 1f rap= 65 rsp= 0 CNXNLESS ESTABLISHED notify=0
defaults assumed=1
txrty=0 txfail=0 bfrty=0
SrcLrn sid= 25 rap= 10 rsp= 1 CNXN-OR ESTABLISHED notify=5
defaults assumed=0
txrty=0 txfail=0 bfrty=0
CS Ni Evt sid= 1c rap= 64 rsp= 3 CNXNLESS ESTABLISHED notify=0
defaults assumed=0
txrty=0 txfail=0 bfrty=0
CS Mac sid= 1c rap= 64 rsp= 11 CNXNLESS ESTABLISHED notify=0
defaults assumed=0
txrty=0 txfail=0 bfrty=0
Cfg Mgr sid= 1d rap= 66 rsp= 3 CNXNLESS ESTABLISHED notify=0
defaults assumed=1
txrty=0 txfail=0 bfrty=0
CLI sid= 1d rap= 67 rsp= 67 CNXNLESS ESTABLISHED notify=0
