DVMRP Troubleshooting Troubleshooting DVMRP
page 15-20 OmniSwitch Troubleshooting Guide September 2005
100| 172.100.1.25| 255.255.255.0| 1| 0|
515| 172.65.1.25| 255.255.0.0| 1| 1|
-> debug ip dvmrp group
Vlan | Group | G Mode | Src | S Mode
-> debug ip dvmrp prune
************Prune Table******************
| Actn| Source | Group| Neighbor| Time|Vlan| Exp
total=0
7800-1 -> debug ip dvmrp graft
***********Graft Status******************
| Source | Group| Neighbor|Vlan| Ack|Time
-> debug ip dvmrp timer
CALLOUT QUEUE:
[PRB3] id=365 time=1
[PRB4] id=366 time=2
[PRB5] id=367 time=2
[PRB1] id=368 time=2
[PRB2] id=370 time=2
[RRT V515] id=348 time=16
[NBT V515] id=369 time=8
-> debug ip dvmrp rib ageq
No. Addr/Mask UpVl UpGw Age Exp Kids Subs
1 172.66.0.0/16
515 172.65.1.23 00h:04m:35s 01m:44s 1 0
-> debug ip dvmrp rib holdq
No. Addr/Mask UpVl UpGw Age Exp Kids Subs
->
