Warnings about use of small microspheres
• Careful consideration should be given whenever use is
contemplated of embolic agents that are smaller in diameter
than the resolution capability of your imaging equipment. The
presence of arteriovenous anastomoses, branch vessels
leading away from the target area or emergent vessels not
evident prior to embolization can lead to mistargeted
embolization and severe complications.
• Microspheres smaller than 100 microns will generally
migrate distal to anastomotic feeders and therefore are more
likely to terminate circulation to distal tissue. Greater potential
ischemic injury results from use of smaller sized microspheres
and consideration must be given to the consequence of this
injury prior to embolization. The potential consequences
include: swelling, necrosis, paralysis, abscess and/or stronger
post embolization syndrome.
• Post-embolization swelling may result in ischemia to tissue
adjacent to target area. Care must be given to avoid ischemia-
intolerant, nontargeted tissue such as nervous tissue.

INSTRUCTIONS
• Position the catheter at the desired site and perform
baseline angiography to evaluate the blood supply of the
lesion.
• EmboGold Microspheres are available in a range of sizes.
Because of the potential for misembolization and the inherent
variability in sphere sizes, the physician should be sure to
carefully select the size of EmboGold Microspheres according
to the size of the target vessels at the desired level of

occlusion in the vasculature.
• Carefully select the size of microspheres according to the
size of the vessels identified and the catheter used. EmboGold
Microspheres are flexible microspheres that support
temporary compression by 20 to 30% to facilitate passage
through microcatheters. Studies have shown a direct
correlation between the size of microspheres and the size of
occluded vessels.
• Inspect packaging and syringe before use to ensure that
they are intact. The external surface of the syringe is sterile.
• Unscrew the cap of the EmboGold Microspheres prefilled
syringe and gently draw contrast agent directly into the
reservoir syringe.
• The ideal suspension is usually obtained with a mixture of
50% contrast agent and 50% saline solution. To obtain a
homogeneous suspension of EmboGold Microspheres, gently
invert the 20-ml syringe several times. Contrast agent and
0.9% NaCl solution can be added in the same proportions to
obtain a more diluted suspension.
Do not use the 20-ml prefilled syringe to inject
EmboGold Microspheres through the catheter!
• Remove all air from the syringe and connect it to one hub of
the three-way stopcock.
• Draw up the suspension using a small syringe (1 to 3 cc)
connected to another hub of the three-way stopcock. Avoid
back and forth movements to reduce the risk of introducing air
into the system. Check that the desired quantity and
concentration of microspheres are used.
• Remove all air from the syringe.

• Screw the syringe onto the hub of the catheter, using the
male Luer-lock connector of the stopcock.
• Open stopcock to connect the injection syringe with the
catheter.
• Under continuous fluoroscopic control, slowly infuse
microspheres into the blood stream. Always inject under free
flow conditions. Reflux of microspheres can induce immediate
ischaemia of healthy tissues or vessels.
• Continue infusion until the desired devascularisation is
obtained. Studies have shown that EmboGold Microspheres
penetrate more distally into the lesion than PVA particles of
similar size. Reduction of the arterial blood supply to the lesion
is therefore more progressive.
• At the end of the infusion, remove the catheter while
maintaining gentle aspiration to avoid dislodging any residual
microspheres still inside the catheter, then close the threeway
stopcock.
• Remove the catheter.
• Discard any remaining EmboGold Microspheres and the
used syringes.

CONSERVATION AND STORAGE
EmboGold Microspheres must be stored in a cool, dry, dark
place in their original syringe and packaging. Use by the date
indicated on the labels of the outer box and blister’s pack. Do
not freeze.

Information on packaging:

All serious or life-threatening adverse events or deaths
associated with use of EmboGold Microspheres should be
reported to the device manufacturer.

Size Range

(µm)

Color Code

1 ml

2 ml

40-120

Orange

S110EG

S120EG

100-300

Yellow

S210EG

S220EG

300-500

Blue

S410EG

S420EG

500-700

Red

S610EG

S620EG

700-900

Green

S810EG

S820EG

900-1200

Purple

S1010EG

S1020EG

Symbol

Designation

Manufacturer: Name & Address

Use by date: year-month

LOT

Batch code

REF

Catalogue number

STERILIZE

2

Do not resterilize

Do not use if package is damaged

Keep away from sunlight

Keep dry

2

Do not re-use

Caution - Refer to Instructions For Use

Non-pyrogenic

STERILE

Sterilized using steam

0°C

Lower limit of temperature

EC mark logo - Notified body identification : 0459
