Additional Surveys:
1. If the base station is moved to a new location, a new survey is required to obtain absolute accuracy. The
base station will provide its best known position until a full survey is completed. It is recommended that
any new base station locations be at least 33 ft (10 m) from an existing saved location.
2. Follow the process in Initial Survey to survey additional locations.
3. After the additional survey has completed averaging position data for 24 hours, the base station will add
the new location to its data base.
4. The new location will be added as a potential candidate for future power ups.
Power Up At a Previously Surveyed Location:
1. Place the base station in exactly the same location as the previously surveyed location.
2. After applying power to the base station, monitor the LEDs on the front panel.
3. The base station will check the last known position.
4. Upon validating a stored position, the ST LED will stop blinking and be steadily lit, indicating that it has
validated its location and is outputting the stored location.
Technician Cables and Connecting to a Base Station:
Table 1: Technician Cable Kits
Tech Cable
P/N
Power Cable
P/N
Instructions
P/N
Also Required
(user sourced)
Ag Leader Kit
P/N
Mobile Base 201-0176-01 4002145 4002138 N/A 4002135
External Radio &
Repeater
201-0221-01 4002145 4002138
Benco kit p/n
215303
4002136
Tower Base GPS
Receiver
201-0177-01 4002145 4002138 N/A 4002137
Benco kit p/n 215303 is needed to communicate with the External Radio when mounted on a tower or other
tall structure. This allows a PC to communicate with the External Radio via the data cable that connects the
External Radio to the GPS Receiver.
The kit includes:
• Tower Gender Adapter Cable
• Serial Port Adaptor Cable
• RS-422 to RS-232 Converter
It is available by contacting directly:
Benco Products Inc.
27065 South Mueller Ave
Sioux Falls, SD 57108-8102
Phone: (605) 213-1010
