15
Figure 16 - AFLink Pgm Util screen for intermediate and advanced users
The output power choices depend on the type of radio as shown in Table 2.
Satelline – 3AS Satelline – 3AS EPIC
10 mW 1 W
20 mW 2 W
50 mW 5 W
100 mW 10 W
200 mW
500 mW
1000 mW
Table 2 - Satel radio output power choices
Figure 17 shows an example of the power choices for a 3AS radio. Also note that in this case, the label
under the Detect Radio button shows that the radio is 3AS.
