11
AF Link Programming Utility:
Installation:
The software package includes 2 files:
•
AFLinkPgmUtil.exe
•
AFLink Programming Utility User Manual
The User Manual listed here above is this user manual.
Description of the Software:
When starting up the software, you will see a window as shown on Figure 10.
Figure 10 - AFLink Pgm Util startup screen
At this point, the user can both right click the window and choose the About option (Figure 11) or press the
Detect Radio button (or Alt+D) to start detecting a connected radio.
Figure 11 - Basic pop-up menu
When choosing the About option from the pop-up menu, the software displays the About window which
shows information such as the software version number as shown on Figure 12 here below.
