Port tree
Use this tree to find information about user authentication on each port. When you select a port
from this tree, the Authentication Information (Target) list on the right provides user information of
the hosts that are registered on the port. In addition, the Authentication Information (Host) list below
the Authentication Information (Target) list provides the user information of the selected port.
Double-click the Fibre folder to view all fibre channel ports in the storage system. The Fibre folder
is available only if the storage system contains a fibre channel adapter. Double-click the fibre
channel ports to view host groups in that port. The host group name appears beside the icon.
Description Item
Indicates a fibre channel port.
CLX-Y
Indicates that the host group performs authentication of hosts.
host group name
Indicates that the host group does not perform authentication of hosts.
host group name
Authentication window 423
