Description
Item
Displays the used capacity of tier 2. If the logical volume is not the volume other
than V-VOL, or if tier 2 does not exist, a hyphen (-) is displayed.
Capacity - Tier2
Displays the used capacity of tier 3. If the logical volume is not the volume other
than V-VOL, or if tier 3 does not exist, a hyphen (-) is displayed.
Capacity - Tier3
Displays the type for each logical volume.
Provisioning Type
•
Basic: Internal volume.
•
External: External volume.
•
THP: V-VOL of Thin Provisioning.
•
Snapshot: Fast Snap volume or Snapshot volume.
The cache logical partition number, displayed as ID:CLPR.
CLPR
Displays the tiering policy name and ID.
Tiering Policy
All(0): Policy specified when all tiers in the pool are used.
Level1(1) to Level31(31): Policy selected from Level1 to Level31, set to the V-VOL.
-: The logical volume is not the Smart Tiers or Smart Tiers Z V-VOL.
Displays the new page assignment tier of the tiering policy. See
New Page Assignment Tier
-: The logical volume is not the Smart Tiers or Smart Tiers Z V-VOL.
Displays whether tier relocation is set to Enable or Disable. If the logical volume
is not to the V-VOL of Smart Tiers or Smart Tiers Z, a hyphen (-) is displayed.
Tier Relocation
Displays the attribute of the LDEV.
Attribute
•
Command Device: Command device.
•
Remote Command Device: Remote command device.
•
Online Data Migration: Volume for online data migration.
•
-: Volume in which the attribute is not defined.
Displays the access attribute of the LDEV.
Access Attribute
1
Displays the total number of relevant paths and alternative paths.
Number of Paths
Opens the Add LUN Paths window.
Add LUN Paths
Opens the Copy LUN Path window.
Copy LUN Paths
Opens the Edit Command Devices window.
Edit Command Devices
Displays the Host-Reserved LUNs window.
View Host-Reserved LUNs
2
Opens the Delete LUN Paths window.
Delete LUN Paths
2
Opens the Edit UUIDs window.
Edit UUIDs
2
Opens a window where you can export configuration information listed in the
table to a file that can be used for multiple purposes, such as backup or reporting.
Export
2
1
Does not appear by default. To display this item, change the Column Settings of the table option. For details about
the Column Settings window, see the HP P9000 Remote Web Console User Guide.
2
Appears when you click More Actions.
