Description Item
Correction Access: Access attribute is being corrected.
Copying: Data in the volume is being copied.
Read Only: Data cannot be written on a read-only volume.
Shredding: Volume is being shredded.
Hyphen (-): Any status other than the above.
The RAID level. An asterisk "*" indicates that the parity group to which the LDEV
belongs is interleaved (concatenated). RAID Level
The capacity of the free space. The control information, such as control cylinders,
used by the storage system is not included in the displayed capacity. Capacity - Free
The total capacity of the LDEVs and "Capacity - Free" is displayed. Capacity - Total
The drive type and rpm in use on this LDEV. Drive Type/RPM
The interleaved (concatenated) parity groups. Interleaved Parity Groups
The number of unallocated LDEVs. Number of LDEVs- Unallocated
The total number of LDEVs. Number of LDEVs - Total
LDEVs tab
Description Item
The LDEV identifier, which is the combination of LDKC, CU, and LDEV. LDEV ID
The LDEV name. LDEV Name
The LDEV status. Status
Normal: Normal status.
Blocked: Host cannot access a blocked volume.
Warning: Problem occurs in the volume.
Formatting: Volume is being formatted.
Preparing Quick Format: Volume is being prepared for quick formatting.
Quick Formatting: Volume is being quick-formatted.
Correction Access: Access attribute is being corrected.
Copying: Data in the volume is being copied.
Read Only: Data cannot be written on a read-only volume.
Shredding: Volume is being shredded.
Hyphen (-): Any status other than the above.
The emulation type. Emulation Type
The capacity of the selected LDEV. Individual Capacity
254 LDEV GUI reference
