Selected Host Groups table
Description Item
The identifier of the port. Port ID
The name of the host group. Host Group Name
The host mode of the host group. Host Mode
The attribute of the port indicating I/O flow. Port Attribute
• Initiator: Issues I/O commands to a target port when I/O is executed
between storage systems with Continuous Access Synchronous, and so
on.
• Target: Receives I/O commands from a host.
•
RCU Target: Receives I/O commands from an initiator when I/O is
executed between storage systems with Continuous Access Synchronous,
and so on.
• External: Issues I/O commands to a target port of an external storage
system with External Storage.
The LUN security setting (enable or disable) on the port. Port Security
The number of hosts registered in the host group. Number of Hosts
Added LUNs table
Description Item
The identifier of the added logical unit. LUN ID
The LDEV identifier, which is the combination of LDKC, CU, and LDEV. LDEV ID
The name of the LDEV. LDEV Name
The emulation types for each logical volume (or logical device). For LUSE
volumes, an asterisk (*) and a number appear on the right of the emulation Emulation Type
type. For example, OPEN-9*3 indicates that three OPEN-9 volumes are
combined.
The size of each logical volume. Capacity
Displays the IDs of parity groups. Parity Group ID
Displays the number of paths set to the relevant LDEV. Number of Paths
