Hosts tab
Description Item
The identifier of the port. Port ID
The HBA WWNs and their icons. HBA WWN
The name of the host. Host Name
The name of the host group. Host Group Name
Opens the Add to Host Groups window. Add to Host Groups
Opens the Edit Host window. Edit Host
Opens the Add Hosts window Add Hosts
Opens the Remove Hosts window. Remove Hosts*
Opens the Add Hosts window. Add Hosts
Opens a window where you can export configuration information listed in the
table to a file that can be used for multiple purposes, such as backup or reporting. Export
Available by clicking More Actions.
LUNs tab
This tab provides information about the LU paths that correspond to the LDEV assigned to the
logged-in user.
Description Item
The identifier of the port. Port ID
The icons and identifiers of the logical unit. Clicking a LUN ID opens the LUN
Properties window. LUN ID
The LDEV identifier, which is the combination of LDKC, CU, and LDEV. LDEV ID
Clicking an LDEV ID takes you to the LDEV Properties window.
The name of each LDEV. LDEV Name
Displays the pool name and pool ID. If the logical volume is not the volume other
than V-VOL, a hyphen (-) is displayed. Pool Name (ID)
The emulation types for each logical volume (or logical device). For LUSE volumes,
an asterisk (*) and a number appear on the right of the emulation type. For
example, OPEN-9*3 indicates that three OPEN-9 volumes are combined. Emulation Type
Displays the logical volume capacity. Capacity - Total
Displays the V-VOL used capacity. Capacity - Used
The Total value displayed might be larger than the Used value due to following
reasons:
• Used displays the used capacity of the V-VOL that is rounded up on each
page.
•
If the emulation type is 3390-A, the used capacity of V-VOL includes the
capacity of the control cylinders (7 Cyl is required per 1,113 Cyl).
If the logical volume is not the volume other than V-VOL, a hyphen (-) is displayed.
Displays the V-VOL usage level. If the logical volume is not the volume other than
V-VOL, a hyphen (-) is displayed. Capacity - Used(%)
Displays the used capacity of tier 1. If the logical volume is not the volume other
than V-VOL, a hyphen (-) is displayed. Capacity - Tier1
Port/Hosts window when selecting a host group under the port of Ports/Host Groups 371
