Summary
Description Item
The total number of target ports. Target
The total number of RCU Target ports. RCU Target
The total number of Initiator ports. Initiator
The total number of External ports. External
The total number of ports. Total
Host Groups tab
This tab provides information about the host groups that are assigned to the logged-on user.
Description Item
The identifier of the port. Port ID
Clicking a port ID opens the port information window.
The icons and names of the host group. Host Group Name
Clicking a host group name opens the host group information window where
you can view information about that host group.
The host mode of the host group. Host Mode
The LUN security setting (enabled or disabled) on the port. Port Security
The number of hosts set to the relevant port. Number of Hosts
The number of logical units. Number of LUNs
The resource group name and identifier of the host groups. Resource Group Name (ID)
Opens the Create Host Groups window. Create Host Groups
Opens the Add LUN Paths window. Add LUN Paths
Opens the Add Hosts window. Add Hosts
Opens the Delete Host Groups window. Delete Host Groups*
Opens the Edit Host Groups window. Edit Host Groups*
Opens the Create Alternative LUN Paths window. Create Alternative LUN Paths*
Opens a window where you can export configuration information listed in the
table to a file that can be used for multiple purposes, such as backup or reporting. Export*
*Available by clicking More Actions.
Hosts tab
This tab provides information about the HBA WWNs that are registered to the host groups assigned
to the logged-on user.
Description Item
The identifier of the port. Port ID
Clicking a port ID opens the port information window.
The HBA WWNs and their icons. HBA WWN
The name of hosts. Host Name
364 LUN Manager GUI reference
