Chapter 8: Server Management
70
21. Remove the nine screws and the two hex jackscrews that secure the video connector to the I/O
Baseboard in order to separate it from the I/O Baseboard tray.
Installing the I/O Baseboard
To install the I/O Baseboard, complete the following procedure:
1. Observe all safety and ESD precautions for handling electronic components.
2. Install the I/O Baseboard into the I/O Baseboard tray.
3. Orient the I/O Baseboard and tray assembly such that the connector end faces the Sideplane.
4. Angle the I/O Baseboard such that the side with the two extraction/installation levers lowers
into the chassis first.
5. Slide the lever end of the I/O Baseboard against chassis frame then lower the connector end
into the chassis.
6. Slide the I/O Baseboard towards the Sideplane until lever aligns with the locking slots.
7. Rotate the levers downward to press the I/O Baseboard securely into the Sideplane.
8. Connect the Internal SCSI cable to the front of the I/O Baseboard.
9 Install the plastic shield over the I/O Baseboard and tighten the two thumbscrews that secure
the shield and the I/O Baseboard in the chassis.
10. Connect the PCI LED cable.
11. Install the DC-DC converters on the Sideplane. The voltages are marked on the power supplies
and near the sockets on the baseboard.
12. Install the protective cover over the DC-to-DC converters on the Sideplane, and secure the
cover with the thumbscrew.
13. Connect the cable to the external SCSI port at both ends: one to the I/O Baseboard and the
other secured to the rear of the chassis with the captive thumbscrew.
14. Install the Legacy I/O board and cables as described in “Installing the Legacy I/O Board”.
15. Install the non-hot plug PCI and hot plug PCI adapter boards as described in “Installing
Accessory Boards” in Chapter 7.
16. Install all PCI slot plastic dividers (I/O Card Dividers) as required.
17. Install the top cover as described in “Replacing the Top Cover” in
Chapter 2.
18. Attach the non-hot plug PCI adapter board cover and secure it with its screw.
19. Close the PCI I/O access door, and secure it with the two captive thumbscrews.
20. Reconnect the power cables.
