Chapter 11: Troubleshooting
121
HP Server rx4610 Sensor Codes
Sensor
Type Sensor
Number
Sensor Name
00 Spare Sensor
09 Spare Sensor 1
14 Spare Sensor 2
01 Temperature
01 Backplane (HSC TeeDock) Temperature
02 HSC SCSI Backplane Temperature
21 Processor 0 Core Temperature
22 Processor 1 Core Temperature
23 Processor 2 Core Temperature
24 Processor 3 Core Temperature
25 Upper Memory Board Temperature
26 Lower Memory Board Temperature
27 Sideplane Temperature
28 I/O Board Temperature
29 Processor Board Temperature 1
2A Processor Board Temperature 2
02 Voltage
07 Baseboard +1.5 Volt
08 Baseboard +1.8 Volt
0A Baseboard +2.8 Volt
0B Baseboard +3.3 Volt
0C Baseboard +3.3 Volt SB
0D Baseboard +5 Volt
0E Baseboard +5 Volt SB
0F Baseboard +12 Volt
10 Baseboard –12 Volt
11 Processor Board +1.5 Volt
12 Processor Board +1.8 Volt
13 Processor Board +3.3 Volt
15 SCSI TERM Volt 00
16 SCSI TERM Volt 01
17 SCSI TERM Volt 02
18 SCSI TERM Volt 10
