Chapter 1: Controls, Ports, and Indicators
9
PCI LEDs
Each PCI slot has four indicator LEDs: two on the outside and two on the inside of the system. The
two LEDs for each slot: one amber and one green are visible from the rear (also inside) of the HP
Server, as shown in Figure 1-7. Eight of the ten PCI slots can be individually powered down through
the respective NOS or supported GUI utility, without powering down the entire HP Server, if the
board has a Hot Plug compliant driver.
Status Indicators for PCI Cards
Figure 1-7. Status Indicators for PCI Boards
