Appendix A: Specifications
168
Pin Signal Pin Signal
20 Keyed 40 GND
PCI
PCI connectors exist inside the chassis on the I/O Baseboard.
Table A-13. 33MHz, 64-bit PCI Connectors (Slots 1 and 2)
Pin Signal Pin Signal Pin Signal Pin Signal
A1 TRST_L A48 GND B1 -12V B48 AD10
A2 +12V A49 AD9 B2 TCK B49 M66EN
A3 TMS A50 5V KEYWAY B3 GND B50 5V KEYWAY
A4 TDI A51 5V KEYWAY B4 TDO B51 5V KEYWAY
A5 +5V A52 C/BEO_L B5 +5V B52 AD8
A6 INTA_L A53 +3.3V B6 +5V B53 AD7
A7 INTC_L A54 AD6 B7 INTB_L B54 +3.3V
A8 +5V A55 AD4 B8 INTD_L B55 AD5
A9 RESERVED A56 GND B9 PRSNT1_L B56 AD3
A10 +5V A57 AD2 B10 RESERVED B57 GND
A11 RESERVED A58 AD0 B11 PRSNT2_L B58 AD1
A12 GND A59 +5V B12 GND B59 +5V
A13 GND A60 REQ64_L B13 GND B60 ACK64_L
A14 RESERVED A61 +5V B14 RESERVED B61 +5V
A15 RESET_L A62 +5V B15 GND B62 +5V
A16 +5V A63 GND B16 CLK B63 RESERVED
A17 GRANT_L A64 C/BE7_L B17 GND B64 GND
A18 GND A65 C/BE5_L B18 REQ_L B65 C/BE6_L
A19 RESERVED A66 +5V B19 +5V B66 C/BE4_L
A20 AD30 A67 PAR64 B20 AD31 B67 GND
A21 +3.3V A68 AD62 B21 AD29 B68 AD63
A22 AD28 A69 GND B22 GND B69 AD61
A23 AD26 A70 AD60 B23 AD27 B70 +5V
A24 GND A71 AD58 B24 AD25 B71 AD59
A25 AD24 A72 GND B25 +3.3V B72 AD57
A26 IDSEL A73 AD56 B26 C/BE3_L B73 GND
A27 +3.3V A74 AD54 B27 AD23 B74 AD55
A28 AD22 A75 +5V B28 GND B75 AD53
A29 AD20 A76 AD52 B29 AD21 B76 GND
A30 GND A77 AD50 B30 AD19 B77 AD51
A31 AD18 A78 GND B31 +3.3V B78 AD49
A32 AD16 A79 AD48 B32 AD17 B79 +5V
A33 +3.3V A80 AD46 B33 C/BE2_L B80 AD47
