Appendix A: Specifications
183
Power Distribution Board Jumpers (T-Docking)
Jumper blocks exist on the Power Distribution Board (T-Docking) that allow you to force a firmware
update, flash bootblock write enable, and configure for 220 Volt brownout protection. To access
these jumper blocks you need expose the T-Docking Board by following the instructions in Chapter 8,
“Server Management Boards”.
J 4D 1
J 4E 2
J 4E 1
Figure A-24. T-Docking Board Jumper Locations
Jumper setting labeled:
Jumper Function
J4E1 Force Firmware Update
J4E2 Flash Bootblock Enable
J4D1 220V Brownout Protection
