17
3 Installing Fans and Power Supplies
Introduction
The fans and power supplies used by the HP Server are hot swappable. The HP Server has four 172
mm fans located on each side of the chassis and two 120 mm cooling fans located on the top front of
the chassis. The server has a maximum of four 800 watt autoranging power supplies located in the
front of the chassis. This chapter describes the procedures necessary to remove and to replace these
components.
Tools and Supplies Needed
• Phillips (cross-head) screwdriver (#2 bit)
• Antistatic wrist strap (recommended)
• Pen or pencil
• Equipment Log
To record the model and serial numbers of the server, all installed options, and any other pertinent
information about the server, see Appendix B, “Equipment Log and Configuration Worksheet”.
WARNING Make sure that the rack is anchored securely, so it will not tip when the server
chassis is extended.
