Chapter 11: Troubleshooting
125
BIOS Error Codes\Messages
The following list defines the BIOS error codes on the HP Server rx4610 server system. All BIOS
error codes\messages, when encountered, appears on the video and are logged in the SEL unless it is
full.
The system event log record for these BIOS error codes has a sensor type of ‘0F’. To decode a BIOS
error codes\message, use the last two bytes in the event description to identify the specific error.
0100: Timer Error
0103: CMOS Battery Low
0104: CMOS Settings Wrong
0105: CMOS/GPNV Checksum Bad
0106: CMOS Display Type Wrong
0108: Unlock Keyboard
0109: Keyboard Error
010A: KB/Interface Error
010B: Memory Size Decrease
010E: Cache Memory Error
0117: Pri Master Drive - ATAPI Incompatible
0118: Pri Slave Drive - ATAPI Incompatible
0119: Sec Master Drive - ATAPI Incompatible
011A: Sec Slave Drive - ATAPI Incompatible
011B: CMOS Date/Time Not Set
011E: Cache Memory Error
0120: NVRAM cleared By jumper
0121: Password cleared By jumper
0141: PCI Memory Conflict
0142: PCI IO Conflict
0143: PCI IRQ Conflict
0144: Shadow of PCI ROM Failed
0145: PCI ROM not found, May Be OK For This Card
0146: Insufficient Memory to Shadow PCI ROM
8100: BIST Failure : Processor in socket M0
8101: BIST Failure : Processor in socket M1
8102: BIST Failure : Processor in socket M2
