Chapter 4: Installing Mass Storage Devices

33

Installing the Hard Disk Bay

To install the Hard Disk Bay, complete the following steps:

1. Turn off the system by using the power on/off switch on the front of the chassis and remove

both AC power cords.

2. If the front bezel is not already removed, remove the bezel.

3. Align the Hard Disk Bay such that the connector side is facing into the chassis and push the

bay into the front of the chassis.

4. Ensure the drive bay seats into the front connector on the Power Distribution Board (T-

Docking Board).

5. Replace the four screws at the top and bottom of the bay.

6. Replace any disk drives into drive bay as required.

7. Replace the Front Bezel.
