Full menu mode
Utilities
Service config
7-5
Company confidential. Postillo/755CM User’s Guide Final Freeze Status:Frozen
This is the cyan on page 7-5 (seq: 145)
This is the black on page 7-5 (seq: 145)
Recalibrating the Printer for Accuracy
When to Recalibrate the Printer
Your printer was calibrated at the factory using HP Matte Film, with a thickness of
0.12 mm (0.0048 in);
at 23
_C (73_F),
with 50-60% relative humidity.
It will operate with greatest accuracy in similar environmental conditions. If you
are operating under significantly different conditions, you should recalibrate the
printer as explained here. The printer’s environmental specifications are given on
page 11-4. Also, if you are using a non-standard media type, you should first
recalibrate the printer for that media type. For supported media types, see
page 3-3. You may also need to recalibrate the printer if you have banding
problems, see page 9-20.
A Quick Guide to Whether Recalibration is Necessary
1 Make sure E/A0-size or D/A1-size media is loaded.
2 Print the Service Configuration print, by choosing the option shown in the menu
graphic on the left.
3 Near the top of this print are a pair of Xs. With a ruler measure the distance
between them. It should be 500 mm. If significantly different you will need to
recalibrate the printer as described on the following page
X X 500mm
Reconfiguring Your Printer
Recalibrating the Printer for Accuracy
RECONFIG.
7
