All menu modes
Default: Software
Page format
Size
4-5
Company confidential. Postillo/755CM User’s Guide Final Freeze Status:Frozen
This is the cyan on page 4-5 (seq: 103)
This is the black on page 4-5 (seq: 103)
Non-PostScript files
Size
in Front Panel Comments
Software The printer looks to the print you have sent
for a page size instruction. If it is present the
printer uses this. If not, the printed page size
is the inked area plus margins.
Inked area The printed page size is the inked area plus
margins. For a definition of “inked area”, see
page 4-2.
ISO Best ISO A “Best ...” options
ISO A0/1/2/3/4
The printer chooses the smallest page size
(from the A-series: A4, A3 etc.) that will hold
ANSI Best ANSI
(from the A series: A4, A3 etc.) that will hold
the inked area of the print. For example, if the
inked area of the print is between A3 and A4
ANSI E/D/C/B/A
inked area of the rint is between A3 and A4,
the printer chooses A3 as the page size.
JIS Best JIS B Discrete options
ISO
A0/1/2/3/4
JIS B1/2/3/4
ISO A0/1/2/3/4
ANSI E/D/C/B/A
JIS B1/2/3/4
ARCH Best ARCH
JIS B1/2/3/4
ARCH E1/E/D/C/B/A
ARCH E1/E/D/C/B/A Over A1/2
The printed page size is exactly the size you
Oversize (No “Best” option)
The printed page size is exactly the size you
specify. The largest discrete page size you
Over A1/A2
y g g y
can specify is E/A0.
If you need to adjust the page size from the front panel, do so before sending the
file from your computer, as the printer determines the size of a print at the time it is
received from your application.
P
AGE
FORMA
T
4
Controlling the Page Format
Page Size
PS
