Property To Association Name
Dependent
HPSVSP_StripeSet : CIM_CompositeExtent
or
HPSVSP_ImportedExtent :
CIM_StorageExtent
HPSVSP_ConfiguredExtentBasedOn :
CIM_BasedOn
PartComponent
HPSVSP_ImportedExtent : CIM_StorageEx-
tent HPSVSP_SystemConfiguredComponentEx-
tent : CIM_SystemDevice
HPSVSP_AssociatedComponentExtent : CIM_AssociatedComponentExtent
Class introduction
This class associates a representation of a disk or stripe set used in a pool to the representation of
that pool.
Once a stripe set is created from a set of disks, then the StripeSet becomes the
AssociatedComponentExtent, rather than disks on which it is based.
Class keys/properties
Comments Property name
Mandatory HPSVSP_ConfiguredPool REF GroupComponent
Mandatory HPSVSP_ConfiguredComponentExtent REF PartComponent
HPSVSP_RemainingConfiguredExtent : CIM_StorageExtent
Class introduction
This class represents the remainder (or available) capacity on an HPSVSP_ConfiguredComponentExtent.
There is one instance of this class for each HPSVSP_ConfiguredComponentExtent.
The SystemName key represents the SVSP domain name of the back-end LU or stripe set.
Class keys/properties
Comments Description Property name
The CreationClassName of the
scoping virtualizer.
“HPSVSP_StorageAppliance"
SystemCreation-
ClassName
The name of the scoping system.
Same as
HPSVSP_StorageAppliance.Name
SystemName
The name of the class used in the
creation of this instance.
HPSVSP_RemainingConfiguredExtent CreationClassName
Extent Composition Profile 126
