HP Latex 360 Printer - Manual (Page 56)

Load a roll into the printer
To start this procedure, you need to have a roll loaded on the spindle. See Load a roll onto the spindle
on page 46 .
The normal minimum substrate width is 23 inches (584 mm). To load substrates down to a minimum width of
10 inches (254 mm), go to the front panel and press , then Substrate > Substrate handling options >
Enable narrow substrate. With this option, print quality is not guaranteed.
TIP: To load a roll of textile substrate, see The loading accessory (360 only) on page 58 ; and remember to
use the ink collector if the substrate is porous (which textiles usually are).
TIP: When loading very thin or very thick substrates, or substrates with a tendency to curl, you should
follow the manual loading procedure to reduce the risk of substrate jams and printhead crashes; see Assisted
manual load on page 61 .
1.
At the printer's front panel, press , then Load.
Alternatively, press , then Substrate load > Load roll.
2. The load configuration screen appears.
50 Chapter 3 Handle the substrate and troubleshoot substrate issues ENWW
