Physical and Virtual
•
Serviceguard
•
System and Event
•
Virtual Machine
A perspective is available even if there are no such corresponding systems configured and
discovered. In that case, Virtualization Manager will display a page saying there is no information
to display in that particular view. The Logical Server perspective is available only on a Windows
CMS. For other conditions, see the note in
“Purpose of the visualization view” (page 23)
describes each perspective in the Perspective drop down menu.
Table 9 Visualization view perspectives
Similar view:
What it shows:
Perspective
From the Systems Insight Manager
Systems and Event Collections list in the
left-hand navigation area, select HP
BladeSystem
Filters information in compartments to
show only server blades, including
virtual connect domains.
Blade
None
Filters information in the compartments
to show active and inactive Logical
Server collections.
Logical Server
From the Systems Insight Manager
Systems and Event Collections list in the
left-hand navigation area, select All VSE
Resources.
All physical and virtual systems.
Physical systems can show standalone
servers, nPartitions, and other
hardware. A complex can show
physical and virtual systems. Virtual
systems can include an Integrity VM
Host containing Integrity VM systems,
logical servers, and Virtual Connect
domains and servers.
Physical and Virtual
From the Systems Insight Manager
Systems and Event Collections list in the
left-hand navigation area, expand
Clusters by Type then select HP
Serviceguard.
Filters information in compartments to
show only Serviceguard clusters and
their members.
Serviceguard
From the Systems Insight Manager
Systems and Event Collections list in the
left-hand navigation area, select All
Systems.
Goes to the Systems Insight Manager
All VSE Resources page. The default
view is systems; click the Events tab to
view events.
System and Event
From the Systems Insight Manager
Systems and Event Collections list in the
left-hand navigation area, select Virtual
Machine Hosts.
Filters information in compartments to
show Integrity VM, VM Hosts, VMware
ESX, or Microsoft Virtual Server virtual
machines.
Virtual Machine
