Brother PE-DESIGN Ver.432 User Manual
Page 169
160
You can only change the settings of the stitch selected in the
Line sew type
selector of the Sewing
Attributes bar. The other stitch settings display in gray.
To set the region sewing attributes, click the
Region sewing
tab. You can only change the settings
of the stitch selected in the
Region sew type
selector of the Sewing Attributes bar. The other stitch
settings display in gray. When you select a text pattern or the Text entering mode, the
Region sew-
ing
tab displays automatically.
◆
Enter the desired values for each set-
ting either by clicking on the arrows or
by typing the value directly in the edit
box window.
•
A preview image of the stitch reflects
your setting changes each time you
click on an arrow, except for the
Run time(s)
setting.
◆
To restore the default value of an indi-
vidual setting, click its
Default
button.
◆
Click
Apply
to confirm the settings.
◆
Click
Close
to exit.
Line sewing attributes
Zigzag stitch
ZigZag width
Sets the width of the zigzag stitch (when
Zigzag Stitch
is selected for the outline).
Range: 1 ~ 10 mm (0.04 ~ 0.39 inch)
Default: 2 mm (0.08 inch)
Density
Sets the number of lines per inch (when
Zigzag Stitch
is selected for the outline).
Range: 1 ~ 7 lines per mm (25 ~ 178 lines per inch)
Default: 4.5 lines per mm (114 lines per inch)
Running stitch
Run pitch
Sets the pitch of the line sewing (when
Running
Stitch
is selected for the outline).
Range: 1 ~ 10 mm (0.04 ~ 0.39 inch)
Default: 2 mm (0.08 inch)
Run times
Sets the number of times the border will be sewn (when
Running
Stitch
is
selected for the outline).
Range: 1 ~ 5
Default: 1
