Print – Brother PE-DESIGN Ver.432 User Manual
Page 150
141
3
Click
Next Page
to display page 2 containing the sewing information (not available if
Reduced Size
was selected in the
Print Setup
dialog).
This button becomes inactive and the
Prev Page
button becomes active.
4
Click
Prev Page
to go back to the display of the embroidery (not available if
Reduced Size
was
selected in the
Print Setup
dialog).
This button becomes inactive and the
Next Page
button becomes active.
5
Click
Two Page
to display both pages at the same time.
The
Two Page
button is
replaced by the
One
Page
button.
Click
One Page
to display one page at a time. The
Next Page
and
Prev Page
become inactive.
NOTE:
If you need to view an image in detail, displaying only one page at a time allows you to enlarge it
more.
If you want to check the sewing information for individual objects composing your embroidery, you
can do that by clicking
Option – Design Property
.
See also:
“Print Setup” above, “Print” below and “Design Property” on page 174
■
Purpose:
Prints your Design Page and some sewing information.
Shortcut key:
+
Toolbar:
No button for this function
Operation:
1
Click
File
, then
.
A
dialog similar to this will display.
2
Follow the instructions in the Windows manuals and in the manuals of your printer for the next
operations.
Depending on the
Print Type
setting, one or two pages will be printed for one pattern or one hoop
position.
Printing a Design Page for an extra-large embroidery frame (130
×
300 mm, 300
×
130 mm, 100
×
172 mm, or 172
×
100 mm)
If a Design Page for an extra-large embroidery frame is selected, each section of the design is printed on
a separate page.
•
If a 130
×
300 mm or 300
×
130 mm Design Page is selected, the design is divided into sections of
130
×
180 mm or 180
×
130 mm and each section is printed on a separate page.
•
If a 100
×
172 mm or 172
×
100 mm Design Page is selected, the design is divided into sections of
100
×
100 mm and each section is printed on a separate page.
◆
Make the necessary setting.
◆
Click
OK
to print.
◆
Click
Cancel
to exit.
◆
Click
Properties
to change the default
settings of the printer.
Ctrl
P
