Milestone Husky M30/M50 Administrator's Manual
www.milestonesys.com 138 Advanced configuration
Name Description
[List of Defined Matrix
recipients]
Lists any already defined Matrix recipients, that is computers on
which Matrix-triggered video can be displayed.
To change the properties of an already defined Matrix recipient,
select the required Matrix recipient, make the changes in the fields
below the list, then click the Update button.
To remove a Matrix recipient from the list, select the unwanted
Matrix recipient, then click the Delete button.
Name
Name of the Matrix-recipient. Used when you add a new Matrix-
recipient or edit the properties of an existing one. The name
appears in various day-to-day usage situations. Therefore, is a
good idea to use a descriptive and unambiguous name.
Address
IP address of the Matrix recipient, used when adding a new Matrix
recipient or editing the properties of an existing one.
Port
Specify the port number to be used when sending commands to the
Matrix recipient. Used when adding a new Matrix recipient or editing
the properties of an existing one. The Matrix recipient will listen for
commands on this port. By default, port 12345 is used; you can of
course specify another port number.
Password
Specify the password to be used when communicating with the
Matrix recipient. Used when adding a new Matrix recipient or editing
the properties of an existing one
Matrix-recipient is an XProtect
Smart Client
Select if the relevant Matrix-recipient is an XProtect Smart Client. If
you use XProtect Smart Client, distribution of Matrix-triggered live
video takes place slightly differently.
Clear Removes any content in the Name, Address, and Password fields.
Update
Updates the properties of the selected Matrix recipient with the
changes made during editing. Available only if you have edited the
properties of an existing Matrix recipient.
Add
Adds the new Matrix-recipient to the list. Available only if you have
added properties of a new Matrix-recipient in the Name, Address,
Port, Password, and possibly XProtect Smart Client fields.
Matrix event control
The Matrix Event Control tab is used to configure the automatic sending of live video based on
predefined events. You can define exactly which events and cameras to use on a per-Matrix recipient
basis. The Matrix Event Control tab displays the list of Matrix recipients defined on the Matrix
Recipients tab.
Right-clicking a Matrix recipient brings up a list of devices with belonging events. When you select an
event, it will initially be highlighted by a red exclamation mark, indicating that there is additional
configuration to be done. Right-clicking an event brings up a list of options for the selected event:
