The active alarm current setting is read from the meter and displayed when this dialog box is
opened. To change the setting, click the desired selection and then click the Write button.
Alarm Selection
High (21.75 mA)
Low (3.75 mA)
Alarm Current Level:
Write Read Close
NOTE: Save the changes to EEPROM and put the meter in-service after making changes.
pipe iD
The internal diameter of the pipe or the pipe ID can be read from the “Pipe ID” dialog box. To
bring up this box, click the “Configure Meter” pull-down menu on the Main screen and then
select “Pipe ID”.
For insertion style meters, this box allows the user to set the inside pipe diameter to the appro-
priate size. The pipe ID is used to calculate volumetric, mass, and standard flow.
Pipe ID
Pipe ID: in.
1.375
Write Read Close
For wafer style meters, the pipe ID cannot be modified and the Write button is disabled.
NOTE: Save the changes to EEPROM and put the meter in-service after making changes.
low flow Cutoff
The low flow cutoff can be read and configured from the “Low Flow Cutoff” dialog box. To bring
up this box, click the “Configure Meter” pull-down menu on the Main screen and then select
“Low Flow Cutoff”.
Low Flow Cutoff
Low Flow Cutoff Hz 25
Write Read Close
