ConfiGuRe MeTeR Menu
Racine Federated HART Interface Utility
FL_METER
0
4
0
72
0
RWG15
Tag:
PV (Volume)
Model Number:
Analog Output Current:
Percent of Range:
Process Temperature:
Process Pressure:
ft3/min
mA
%
degF
psi
Connect Connect Update
Begin Continuous Display Update
Continuous Screen Update:
Meter In-Service:
Edit Mode:
Fixed Current Value:
Configuration Changed, Not Saved:
Password Protection:
Tools About Com Port Save/Restore Configuration Edit/In-Service Configure Meter Configure Meter
Analog Range Values
Primary Variable
HART Interface
Damping Value
Process Temperature
Process Pressure
Density and Viscosity
LCD Display
Burst Mode
Standard Flow
Password Protection
Alarm Selection
Pipe ID
Low Flow Cutoff
K-Factor
Totalizer Settings
Common buttons
Read
This button will refresh the fields in the dialog box with data read from the meter.
Write
This button will write new data to the meter and refresh the fields in the dialog box with new
data from the meter. If the data sent to the meter was rejected, the fields in the dialog box
will be changed to reflect the actual data in the meter.
Close
This button will close the dialog box. Any changes made to the dialog box that were not
sent to the meter using the Write button will be lost.
