Exiting Edit Mode (Or putting the meter in-service) - To put the meter in-service, click the

“Edit/In-Service” pull-down menu on the Main screen and select “Put Meter In-Service”. The

meter must be put back in-service after making changes to the meter. Otherwise, the analog

output of the meter will not be updated.

Racine Federated HART Interface Utility

FL_METER

RWG15

Tag:

PV (Volume)

Model Number:

Analog Output Current:

Percent of Range:

Process Temperature:

Process Pressure:

ft3/min

degF

psi

Connect

Update

Begin Continuous Display Update

Tools

About

Com Port

Save/Restore Configuration

Configure Meter

Continuous Screen Update:

Fixed Current Value:

Password Protection:

Configuration Changed, Not Saved:

Edit/In-Service

Put Meter In Service

Enter Edit Mode

Meter In-Service

Indicator

Edit Mode

Indicator

Meter In-Service:

Edit Mode:

power up state - Meters containing embedded software version 11 or higher will always

power up “In-Service”. Meters containing earlier embedded software versions will power up in

the same state that they were powered off in.
