Page 88: Mechanical data
SR09D040-C000-0
SR09D040-C000-1
SR09D040-C000-2
Capacity
Nom Cooling (Gross)
(1) kW
42.3
42.3
42.3
Fan Power Input (Fan Gain)
(2) kW
1.45
1.45
1.45
Dimensions - W x D x H
mm
963 x 890 x 1980
Weight - Machine / Operating
(3) kg
307 / 337
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black Grey (RAL 7021)
Material / Colour
Frame: Anodised Aluminium Frame with Aluminium Corners, Epoxy
Baked Powder Coated Paint - Black Grey (RAL 7021)
Cooling Coil
Copper Tube / Hydrophilic Coated Aluminium Fins
Cooling / Dehum Stages
1 (Modulated) / 1
Water volume
l
30
30
30
Water flow rate
l/s
2.01
2.01
2.01
Pressure drop
kPa
37.4
37.4
37.4
Fan & Motor
Backwards Curved, Centrifugal Direct Drive
Motor Type
EC
EC
EC
Quantity x Motor Size
(4) kW
1 x 1.96
1 x 1.96
1 x 1.96
Speed @25Pa ESP / Maximum ESP
rpm
1440 / 1560
1440 / 1560
1440 / 1560
Maximum ESP
Pa
202
202
202
Nominal Airflow
m³/s
2.30
2.30
2.30
Connections
Water Inlet / Outlet -
mm
35
35
35
Condensate Drain Hose
mm
22
22
22
Filtration
Disposable to BS EN 779-G4
Quantity
9
9
9
Electric Heating (Total)
kW
7.5
6.8
7.5
Humidifier
Capacity
kg/hr
8
8
8
Drain pump flow rate
l/m
7
7
7
Feed / Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Hot Water Condensate Pump
Head
m
5
5
5
Flow
l/m
10.8
10.8
10.8
Drain
10mm Stainless Steel Stub Connection
Cold Water Condensate Pump
Head
m
4
4
4
Flow
l/m
1.7
1.7
1.7
Drain
10mm Quarter Turn Plastic ‘Barb’ Connection
Upgraded Fan Motor - EC Motor
Backwards Curved, Centrifugal Direct Drive
Quantity x Motor Size
(4) kW
1 x 3.6
1 x 3.6
1 x 3.6
Speed @ 25Pa / Maximum ESP
rpm
1863 / 2260
1863 / 2260
1932 / 2260
Maximum ESP
Pa
678
678
547
SR09D040-C000
Technical Data SR C000 Units
Mechanical Data
(1) Entering air 24°C /45% RH water 7°C/ 12°C.
(2) Fan Gain / Fan power input based upon fan operating with design airflow at 25Pa ESP, these values may change with different ESP.
(3) Machine weight excludes water charge.
(4) Backward curved EC fan options quote electrical power.
SmartCool™ 6 - 200kW
Precision Air Conditioning
88
SmartCool 6 - 200kW Chilled Water Technical Manual 7674716 V1.1.0_04_2014
