Control Panel Closed (SN, SR Units)
Control Panel Open (SN,SR Units)
Standard Control Panel
Optional Control Panel
Optional Control Panel
Optional Control Panels are
fitted dependent on which
optional featurers are fitted.
SD Units
Electrical Panels
The control panel contains the necessary contactors, transformer, sub circuit protection, volt free contacts for a common
alarm and mains and inter-connecting terminals. The panel is situated within the cabinet and can be opened to allow for
essential maintenance of other components within the unit (SN, SR Units only). The electrical control panels are wired to
the latest European standards and codes of practice.
