Chilled Water Components
System Configuration
Range SN SR SD
Number of Circuits Single Single Dual Single Dual
Chilled W
ater
Hydrophilic Epoxy Coated RTPF Chilled Water Coil
● ● ● ● ●
0-10 Volts Chilled Water Regulating Valve (2 Way)
● ● ● ● ●
0-10 Volts Chilled Water Regulating Valve (3 Way)
○ ○ ○ – –
0-10 Volts Chilled Water Regulating Valve (2 x 2-Way) Auto Commission
– – – ○ ○
Brazed Connection
● ● ● ● ●
Threaded Connections
○ ○ ○ ○ ○
Grooved Connections
– – – ○ ○
●
Standard Features
○
Optional Features
–
Feature Not Available
SD Range
Valves
Cooling Coil
Pipework
Connections
