Airedale SmartCool 11-233kW - Manual (Page 36)

M6 FIXINGS
EIGHT POSITIONS
FRONT REAR
RETURN AIR
DISCHARGE AIR
684 600
1980
171 342 171
270
165
165
570
654 15
15
684
600
Installation Data
Dimensions
SN 06D - C000
SmartCool™ 6 - 200kW Precision Air Conditioning
36 SmartCool 6 - 200kW Chilled Water Technical Manual 7674716 V1.1.0_04_2014
