HUMIDIFIER
(OPTIONAL)
CONDENSATE PUMP
(OPTIONAL)
HUMIDIFIER
FILL
HUMIDIFIER
DRAIN
CONDENSATE
DRAIN
CUSTOMER POWER
CONNECTIONS
POWER IN
CONTROLS
IN
FLOOR
LEVEL
VIEW ON RIGHT HAND SIDE
FRONT OF
UNIT
SR Dual Circuit
VIEW FROM ABOVE
FRONT OF UNIT
A
B
E
F
G
C
D
J
H
111
259
105
1800
343
632.5
811
890
79
92
80
408
556
98
216
75
199
A DIA 42mm CIRCUIT 1 WATER INLET
B DIA 42mm CIRCUIT 1 WATER OUTLET
C DIA 42mm CIRCUIT 2 WATER INLET
D DIA 42mm CIRCUIT 2 WATER OUTLET
E POWER (CONNECT VIA EXTERNAL CONNECTION BOX)
F CONTROLS (CONNECT VIA CONNECTORS)
G CONDENSATE DRAIN (TEE TO HUMIDIFIER DRAIN - IF USED)
H HUMIDIFIER DRAIN (TEE TO CONDENSATE DRAIN)
J HUMIDIFIER FILL
SN, SR Electrical Power Connections
Precision Air Conditioning
SmartCool™ 6 - 200kW
