Page 100: Mechanical data
SR18D095-C000-0
SR18D095-C000-1
SR18D095-C000-2
Capacity
Nom Cooling (Gross)
(1) kW
98.3
98.3
98.3
Fan Power Input (Fan Gain)
(2) kW
3.8
3.8
3.8
Dimensions - W x D x H
mm
1800 x 890 x 1980
Weight - Machine / Operating
(3) kg
528 / 593
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black Grey (RAL 7021)
Material / Colour
Frame: Anodised Aluminium Frame with Aluminium Corners, Epoxy
Baked Powder Coated Paint - Black Grey (RAL 7021)
Cooling Coil
Copper Tube / Hydrophilic Coated Aluminium Fins
Cooling / Dehum Stages
1 (Modulated) / 1
Water volume
l
65
65
65
Water flow rate
l/s
4.68
4.68
4.68
Pressure drop
kPa
46.3
46.3
46.3
Fan & Motor
Backwards Curved, Centrifugal Direct Drive
Motor Type
EC
EC
EC
Quantity x Motor Size
(4) kW
2 x 2.9
2 x 2.9
2 x 2.9
Speed @25Pa ESP / Maximum ESP
rpm
1455 / 1660
1455 / 1660
1455 / 1660
Maximum ESP
Pa
325
325
325
Nominal Airflow
m³/s
5.50
5.50
5.50
Connections
Water Inlet / Outlet -
mm
54
54
54
Condensate Drain Hose
mm
22
22
22
Filtration
Disposable to BS EN 779-G4
Quantity
18
18
18
Electric Heating (Total)
kW
22.5
20.3
22.5
Humidifier
Capacity
kg/hr
15
15
15
Drain pump flow rate
l/m
7
7
7
Feed / Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Hot Water Condensate Pump
Head
m
5
5
5
Flow
l/m
10.8
10.8
10.8
Drain
10mm Stainless Steel Stub Connection
Cold Water Condensate Pump
Head
m
4
4
4
Flow
l/m
1.7
1.7
1.7
Drain
10mm Quarter Turn Plastic ‘Barb’ Connection
Upgraded Fan Motor - EC Motor
Quantity x Motor Size
(4) kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
N/A
N/A
N/A
Maximum ESP
Pa
N/A
N/A
N/A
SR18D095-C000
Technical Data SR C000 Units
Mechanical Data
(1) Entering air 24°C /45% RH water 7°C/ 12°C.
(2) Fan Gain / Fan power input based upon fan operating with design airflow at 25Pa ESP, these values may change with different ESP.
(3) Machine weight excludes water charge.
(4) Backward curved EC fan options quote electrical power.
SmartCool™ 6 - 200kW
Precision Air Conditioning
100
SmartCool 6 - 200kW Chilled Water Technical Manual 7674716 V1.1.0_04_2014
