Page 162
SD18D085-CHCH-0
SD18D085-CHCH-1
SD18D085-CHCH-2
Capacity
Nom Cooling (Gross)
(1) kW
75.2
75.2
75.2
Fan Power Input (Fan Gain)
(2) kW
2.3
2.3
2.3
Dimensions - W x D x H
mm
1800 x 890 x 1980
1800 x 890 x 1980
1800 x 890 x 1980
Weight - Machine Case / Fan Module / Operating (3) kg
477 / 175 / 702
477 / 175 / 702
477 / 175 / 702
Construction
Frame: Sheet Metal Folded Profile, Epoxy Baked Powder Paint / Black Grey (RAL 7021)
Material/Colour
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint / Black Grey (RAL 7021)
Cooling Coil
Copper Tube / Turbulated Hydrophillic Coated Aluminium Fins
Cooling / Dehum Stages
1 (Modulated) / 1
Water Volume
l
50
50
50
Water Flow Rate
l/s
3.6
3.6
3.6
Pressure Drop
kPa
23.0
23.0
23.0
Fan & Motor
Backwards Curved, Centrifugal Direct Drive
Motor Type
EC
EC
EC
Quantity x Motor Size
(4) kW
2 x 2.9
2 x 2.9
2 x 2.9
Speed @25Pa ESP / Maximum ESP
rpm
1266 / 1657
1266 / 1657
1266 / 1657
Maximum ESP
Pa
538
538
538
Nominal Airflow
m³/s
5.3
5.3
5.3
Connections
Water Inlet / Outlet -
mm
54
54
54
Condensate Drain Hose
mm
22
22
22
Filtration
Disposable to BS EN779:2012 - G4 - 75mm Deep
Quantity
6
6
6
Electric Heating (Total)
kW
15.0
13.5
15.0
Humidifier
Capacity
kg/hr
8
8
8
Drain Pump Flow Rate
l/m
7
7
7
Feed / Drain
3/4” BSPF Braided Flexible Hose / 22mm Hose Connection
Hot Water Condensate Pump
Head
m
5
5
5
Flow
l/m
9.0
9.0
9.0
Drain
10mm Stainless Steel Stub Connection
Cold Water Condensate Pump
Head
m
5
5
5
Flow
l/m
3.1
3.1
3.1
Drain
10mm Plastic Barb Connection
Upgraded Fan Motor - EC Motor
Quantity x Motor Size
(4) kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
N/A
N/A
N/A
Maximum ESP
Pa
N/A
N/A
N/A
Technical Data SD CHCH Units
Mechanical Data
SD18D085-CHCH
(1) Entering air 24°C / 45% RH water 7°C / 12°C
(2) Fan gain/ fan power input is shown for a unit delivering nominal air volume with 25Pa ESP. The fan gain / fan power values will change when selected with alternative airflow or
ESP values.
(3) Operating weight includes case and fan module.
(4) Backward curved EC fan options quote electrical power.
SmartCool™ 6 - 200kW
Precision Air Conditioning
162
SmartCool 6 - 200kW Chilled Water Technical Manual 7674716 V1.1.0_04_2014
