Technical Data SD CLCL Units
Electrical Data
SD22D120-CLCL
SD22D120-CLCL-0
SD22D120-CLCL-1
SD22D120-CLCL-2
Unit Data - Full Function
(1)
Nominal Run Amps
A
64.2
64.7
115.6
Recommended Mains Fuse Size
A
80
80
160
Unit Data - Cooling Only
Nominal Run Amps
A
9.9
9.9
17.0
Recommended Mains Fuse Size
A
16
16
20
Max Mains Incoming Cable Size
mm²
70
70
70
Mains Supply
V
400V / 3PH + N / 50Hz
380V / 3PH + N / 60Hz
220V / 3PH / 60Hz
Control Circuit
VAC
24
24
24
Evaporator Fan - Motor - Per Fan
Motor Type
EC
EC
EC
Quantity x Motor Size
(2) kW
2 x 2.9
2 x 2.9
2 x 2.9
Full Load Amps
A
4.5
4.5
7.5
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat
2
2
2
Number of Elements
6
6
6
Rating
kW
15.0
13.5
15.0
Current Per Phase
A
21.7
20.6
39.4
Humidifier
Capacity
kg/hr
30
30
30
Rating
kW
22.5
22.5
22.5
Full Load Amps
A
32.6
34.2
59.2
(1) Values given for full function units with standard selections for heating, humidification, supply air fans.
(2) Stated motor power is based on maximum electrical power absorbed
