Page 86: Mechanical data
SR09D030-C000-0
SR09D030-C000-1
SR09D030-C000-2
Capacity
Nom Cooling (Gross)
(1) kW
34.7
34.7
34.7
Fan Power Input (Fan Gain)
(2) kW
0.8
0.8
0.8
Dimensions - W x D x H
mm
963 x 890 x 1980
Weight - Machine / Operating
(3) kg
307 / 337
Construction
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint - Black Grey (RAL 7021)
Material/Colour
Frame: Anodised Aluminium Frame with Aluminium Corners, Epoxy
Baked Powder Coated Paint - Black Grey (RAL 7021)
Cooling Coil
Copper Tube / Hydrophilic Coated Aluminium Fins
Cooling/Dehum Stages
1 (Modulated) / 1
Water volume
l
30
30
30
Water flow rate
l/s
1.65
1.65
1.65
Pressure drop
kPa
25.9
25.9
25.9
Fan & Motor
Backwards Curved, Centrifugal Direct Drive
Motor Type
EC
EC
EC
Quantity x Motor Size
(4) kW
1 x 1.96
1 x 1.96
1 x 1.96
Speed @25Pa ESP / Maximum ESP
rpm
1174 / 1560
1174 / 1560
1174 / 1560
Maximum ESP
Pa
463
463
463
Nominal Airflow
m³/s
1.85
1.85
1.85
Connections
Water Inlet / Outlet -
mm
35
35
35
Condensate Drain Hose
mm
22
22
22
Filtration
Disposable to BS EN 779-G4
Quantity
9
9
9
Electric Heating (Total)
kW
7.5
6.8
7.5
Humidifier
Capacity
kg/hr
8
8
8
Drain pump flow rate
l/m
7
7
7
Feed / Drain
3/4” BSPF Braided Flexible Hose / 19mm Hose Connection
Hot Water Condensate Pump
Head
m
5
5
5
Flow
l/m
10.8
10.8
10.8
Drain
10mm Stainless Steel Stub Connection
Cold Water Condensate Pump
Head
m
4
4
4
Flow
l/m
1.7
1.7
1.7
Drain
10mm Quarter Turn Plastic ‘Barb’ Connection
Upgraded Fan Motor - EC Motor
Backwards Curved, Centrifugal Direct Drive
Quantity x Motor Size
(4) kW
1 x 3.6
1 x 3.6
1 x 3.6
Speed @ 25Pa / Maximum ESP
rpm
1521 / 2260
1521 / 2260
1527 / 2260
Maximum ESP
Pa
1010
1010
1010
SR09D030-C000
Technical Data SR C000 Units
Mechanical Data
(1) Entering air 24°C /45% RH water 7°C/ 12°C.
(2) Fan Gain / Fan power input based upon fan operating with design airflow at 25Pa ESP, these values may change with different ESP.
(3) Machine weight excludes water charge.
(4) Backward curved EC fan options quote electrical power.
