Smartcool™ 6 - 200kw precision air conditioning, Technical data sd cl00 units, Te ch ni ca l sd c l0 0 – Airedale SmartCool 11-233kW User Manual
Page 154
SD35D270-CL00-0
SD35D270-CL00-1
SD35D270-CL00-2
Capacity
Nom Cooling (Gross)
(1) kW
215.4
215.4
215.4
Fan Power Input (Fan Gain)
(2) kW
7.8
7.8
7.8
Dimensions - W x D x H
mm
3500 x 890 x 1980
3500 x 890 x 1980
3500 x 890 x 1980
Weight - Machine Case / Fan Module / Operating (3) kg
745 / 326 / 1190
745 / 326 / 1190
745 / 326 / 1190
Construction
Frame: Sheet Metal Folded Profile, Epoxy Baked Powder Paint / Black Grey (RAL 7021)
Material/Colour
Panels: Galvanised Sheet Steel, Epoxy Baked Powder Paint / Black Grey (RAL 7021)
Cooling Coil
Copper Tube / Turbulated Hydrophillic Coated Aluminium Fins
Cooling / Dehum Stages
1 (Modulated) / 1
Water Volume
l
120
120
120
Water Flow Rate
l/s
8.6
8.6
8.6
Pressure Drop
kPa
95.1
95.1
95.1
Fan & Motor
Backwards Curved, Centrifugal Direct Drive
Motor Type
EC
EC
EC
Quantity x Motor Size
(4) kW
4 x 2.9
4 x 2.9
4 x 2.9
Speed @25Pa ESP / Maximum ESP
rpm
1532 / 1657
1532 / 1657
1532 / 1657
Maximum ESP
Pa
225
225
225
Nominal Airflow
m³/s
13.0
13.0
13.0
Connections
Water Inlet / Outlet -
mm
67
67
67
Condensate Drain Hose
mm
22
22
22
Filtration
Disposable to BS EN779:2012 - G4 - 75mm Deep
Quantity
9
9
9
Electric Heating (Total)
kW
30.0
27.1
30.0
Humidifier
Capacity
kg/hr
30
30
30
Drain Pump Flow Rate
l/m
7
7
7
Feed / Drain
3/4” BSPF Braided Flexible Hose / 22mm Hose Connection
Hot Water Condensate Pump
Head
m
5
5
5
Flow
l/m
9.0
9.0
9.0
Drain
10mm Stainless Steel Stub Connection
Cold Water Condensate Pump
Head
m
5
5
5
Flow
l/m
3.1
3.1
3.1
Drain
10mm Plastic Barb Connection
Upgraded Fan Motor - EC Motor
Quantity x Motor Size
(4) kW
N/A
N/A
N/A
Speed @ 25Pa / Maximum ESP
rpm
N/A
N/A
N/A
Maximum ESP
Pa
N/A
N/A
N/A
Technical Data SD CL00 Units
Mechanical Data
SD35D270-CL00
(1) Entering air 35°C / 24% RH water 18°C / 24°C
(2) Fan gain/ fan power input is shown for a unit delivering nominal air volume with 25Pa ESP. The fan gain / fan power values will change when selected with alternative airflow or
ESP values.
(3) Machine weight excludes water charge.
(4) Backward curved EC fan options quote electrical power. All other options quote shaft power.
SmartCool™ 6 - 200kW
Precision Air Conditioning
154
SmartCool 6 - 200kW Chilled Water Technical Manual 7674716 V1.1.0_04_2014
