Technical Data SD CHCH Units
Electrical Data
SD18D085-CHCH
SD18D085-CHCH-0
SD18D085-CHCH-1
SD18D085-CHCH-2
Unit Data - Full Function
(1)
Nominal Run Amps
A
40.3
39.7
72.2
Recommended Mains Fuse Size
A
50
50
100
Unit Data - Cooling Only
Nominal Run Amps
A
9.9
9.9
17.0
Recommended Mains Fuse Size
A
16
16
20
Max Mains Incoming Cable Size
mm²
35
35
70
Mains Supply
V
400V / 3PH + N / 50Hz
380V / 3PH + N / 60Hz
220V / 3PH / 60Hz
Control Circuit
VAC
24
24
24
Evaporator Fan - Motor - Per Fan
Motor Type
EC
EC
EC
Quantity x Motor Size
(2) kW
2 x 2.9
2 x 2.9
2 x 2.9
Full Load Amps
A
4.5
4.5
7.5
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat
2
2
2
Number of Elements
6
6
6
Rating
kW
15.0
13.5
15.0
Current Per Phase
A
21.7
20.6
39.4
Humidifier
Capacity
kg/hr
8
8
8
Rating
kW
6.0
6.0
6.0
Full Load Amps
A
8.7
9.2
15.8
(1) Values given for full function units with standard selections for heating, humidification, supply air fans.
(2) Stated motor power is based on maximum electrical power absorbed
