Technical Data SD CL00 Units
Electrical Data
SD25D180-CL00
SD25D180-CL00-0
SD25D180-CL00-1
SD25D180-CL00-2
Unit Data - Full Function
(1)
Nominal Run Amps
A
79.4
79.4
142.8
Recommended Mains Fuse Size
A
100
100
200
Unit Data - Cooling Only
Nominal Run Amps
A
14.3
14.3
24.5
Recommended Mains Fuse Size
A
20
20
32
Max Mains Incoming Cable Size
mm²
70
70
185
Mains Supply
V
400V / 3PH + N / 50Hz
380V / 3PH + N / 60Hz
220V / 3PH / 60Hz
Control Circuit
VAC
24
24
24
Evaporator Fan - Motor - Per Fan
Motor Type
EC
EC
EC
Quantity x Motor Size
(2) kW
3 x 2.9
3 x 2.9
3 x 2.9
Full Load Amps
A
4.5
4.5
7.5
OPTIONAL EXTRAS
Electric Heating
Stage of Reheat
3
3
3
Number of Elements
9
9
9
Rating
kW
22.5
20.3
22.5
Current Per Phase
A
32.5
30.9
59.1
Humidifier
Capacity
kg/hr
30
30
30
Rating
kW
22.5
22.5
22.5
Full Load Amps
A
32.6
34.2
59.2
(1) Values given for full function units with standard selections for heating, humidification, supply air fans.
(2) Stated motor power is based on maximum electrical power absorbed
Precision Air Conditioning
SmartCool™ 6 - 200kW
151
SmartCool 6 - 200kW Chilled Water Technical Manual 7674716 V1.1.0_04_2014
