Overall
dB(A)
Frequency (Hz) dB
Sound Measurement
63
125
250
500
1000
2000
4000
8000
SN06D010-C000
Discharge Air
70
64
66
71
69
64
58
51
27
Return Air
68
64
66
69
68
63
58
50
26
Case Breakout
70
68
71
72
69
64
58
51
30
Sound Pressure @ 3m
56
53
57
58
54
50
44
37
15
SN06D015-C000
Discharge Air
81
75
76
81
80
75
69
62
38
Return Air
79
75
76
79
79
73
68
61
37
Case Breakout
81
79
82
83
80
75
69
62
41
Sound Pressure @ 3m
66
64
67
68
65
61
54
48
26
SN09D020-C000
Discharge Air
69
68
70
74
69
60
57
51
34
Return Air
68
68
70
72
68
58
56
50
34
Case Breakout
70
72
75
76
68
60
56
52
37
Sound Pressure @ 3m
56
57
61
61
54
45
42
37
23
SN09D025-C000
Discharge Air
76
73
72
82
75
67
63
57
40
Return Air
75
73
72
80
74
65
62
56
39
Case Breakout
77
77
77
83
74
67
63
57
43
Sound Pressure @ 3m
62
62
63
69
60
52
48
43
29
SN12D030-C000
Discharge Air
69
65
72
73
67
60
57
56
37
Return Air
68
65
72
71
66
58
56
55
36
Case Breakout
70
69
78
75
67
60
57
57
40
Sound Pressure @ 3m
55
55
63
60
52
45
42
42
26
SN12D035-C000
Discharge Air
73
64
74
78
71
64
62
58
44
Return Air
72
64
73
76
70
62
61
57
43
Case Breakout
74
68
79
79
71
64
61
58
47
Sound Pressure @ 3m
59
53
64
65
56
49
47
44
32
Technical Data
Sound Data
(1) dB(A) is the overall sound level, measured on the A scale
(2) All sound data measured at nominal conditions, Discharge Air, Return air and case breakout is sound power.
